Data sheet:
Height | 90 cm |
Width | 130 cm |
Depth | 115 cm |
Weight | 355 kg |
Electrical connection | 380-415V |
Pump power | 400 W |
Suction motor power | 400 W |
Steam inlet | 1/2 inch |
Return outlet | 1/2 inch |
Steam consumption | 16 – 20 kg/h |
Steam working pressure | 5 bar |
Air working pressure | 6 bar |
Boiler drain | 1/2 inch |
Water connection | Rubber pipe with inner ø 12mm |
Air line | 3/8 inch |
Air consumption | 600 NL/min |
Vacuum depresion | 250 mm H₂O |
Średnica podłączenia odsysacza centralnego | Ø 100 mm |
Vacuum air consumption | 400 m³/h |
Vacuum outlet | Ø 100 mm |
Compressor motor | 750 W |
